To be a legal egress window for a Calgary bedroom or basement suite in 2026, the opening must give at least 0.35 m² (3.77 sq ft) of unobstructed area, with no individual dimension under 380 mm (15″), and a sill no higher than 1.5 m above the finished floor. The window well in front must give at least 760 mm (30″) of clear projection, and any well deeper than 1.2 m (4 ft) needs a built-in ladder or steps.
The governing code is the National Building Code – Alberta Edition (NBC(AE)) 2023, Part 9 (bedroom egress, Article 9.9.10.1) plus the City of Calgary Egress Window Guidelines — not the US IRC. Cutting your foundation for an egress window requires a City of Calgary building permit. (City of Calgary Egress Window Guidelines)
If you’re legalizing a basement bedroom or a secondary suite, the deepest risk isn’t the product — it’s failing inspection or ending up with an unregistered, uninsurable suite. This is the code-fluent checklist most egress pages skip.
The Calgary egress numbers (memorize these four)
These are the verified Calgary figures. Note the units — Alberta works in metric and the National Building Code, not the imperial US IRC numbers you’ll see on American sites.
| Requirement | Calgary / NBC(AE) spec | Source |
|---|---|---|
| Minimum unobstructed opening area | 0.35 m² (3.77 sq ft) | City of Calgary |
| No dimension less than | 380 mm (15″) | City + Great Egress Co |
| Sill height above finished floor | ≤ 1.5 m (recommended) | Ecoline |
| Window well clear projection | ≥ 760 mm (30″) in front of the window | Great Egress Co |
| Ladder/steps required when well depth > | 1.2 m (4 ft) | Windows West |
The opening must be openable from the inside without keys, tools, or special knowledge, and without removing the sash or hardware — that’s the functional definition of egress under NBC(AE) Part 9, Article 9.9.10.1 (Great Egress Co — Alberta requirements; NBC 2023 Alberta Edition Part 9 via BILD Alberta). If the window swings into the well, it must not obstruct the escape path. FLAG: confirm the exact 2023-edition article number — 9.9.10.1 is sourced for the 2019 Alberta Edition and carried forward; cite “NBC(AE) 2023, Part 9” + the City guideline as the durable anchor.
What code does Calgary use — IRC or NBC?
NBC(AE), not the US IRC. This matters because most online egress content is American and cites IRC Section R310 with imperial figures (5.7 sq ft opening, 24″ minimum height, 20″ minimum width, 44″ max sill). Those numbers are wrong for Calgary. Alberta builds to the National Building Code – Alberta Edition, and Calgary layers its own Egress Window Guidelines on top. If a contractor or a product page quotes IRC R310 at you, that’s a red flag they’re working from US references — the kind of mistake that fails a Calgary inspection.
The correct chain of authority for a Calgary egress window: NBC(AE) 2023, Part 9 (the code), the City of Calgary Egress Window Guidelines (the local interpretation), and a City of Calgary building permit (the legal sign-off).
Do I need a permit to cut my foundation for an egress window?
Yes — always, for a new or enlarged egress window. A City of Calgary building permit is required for all new egress window installations, and the reason is structural: enlarging a window means cutting into the foundation wall, and the Building Code restricts the size and percentage of openings allowed in a foundation wall because cutting too much compromises the wall’s ability to resist soil pressure (egress-windows-calgary.com; Emerald Renovations).
This is exactly why a code-fluent supplier and a permitted install matter — an over-cut opening is a structural problem, not just a paperwork one.
Permit fees start around $333.84 (egress-windows-calgary.com). The cost of skipping the permit is far higher: unpermitted work voids insurance, fails a legal-suite inspection, and becomes a problem at resale. Most egress pages quote the dimensions and stop there. The permit and the foundation-opening limit are the parts that actually decide whether your project is legal.
Does my basement suite need to be registered in Calgary?
Yes, if it’s a secondary suite. A building permit is required to legalize a suite that has both a bathroom and cooking facilities, and the City of Calgary Secondary Suite Registry lists the legal, permitted, inspected suites in the city (new secondary suite; existing secondary suite). An egress window in each bedroom is part of what the inspection checks. A suite that isn’t on the registry is, functionally, not a legal rental — which is the renovator’s worst-case outcome: money spent, no rental income, and an insurance and resale liability.
This is the bigger context driving egress demand in 2026: Calgary’s missing-middle and secondary-suite wave (R-CG zoning) has pushed a wave of basement-suite conversions, and every one of them needs compliant egress.
The legalize-a-suite egress checklist
- Confirm the use — a bedroom needs egress; a full secondary suite (bathroom + kitchen) also needs registration.
- Size the opening — ≥ 0.35 m² unobstructed, no dimension < 380 mm, sill ≤ 1.5 m, openable without tools.
- Plan the foundation cut — confirm the opening stays within code limits on foundation-wall openings; this is structural.
- Pull the City building permit — required before cutting; fee from ~$333.84.
- Size the window well — ≥ 760 mm clear projection; if depth > 1.2 m, build in a ladder or steps.
- Engineer the drainage — gravel base below the sill, tied to your weeping tile (see below).
- Pass inspection — and, for a suite, get it onto the Secondary Suite Registry.
Concrete vs metal vs plastic window well — which is best for Calgary?
The well isn’t a trim piece — it’s a retaining structure holding back wet, freezing soil, and it has to drain. Material matters here.
| Material | Lifespan | Calgary verdict |
|---|---|---|
| Concrete | 30–50+ years | No rust, rot, or UV breakdown; mass retains soil and resists frost; carries an egress ladder cleanly |
| Galvanized steel (corrugated) | 20–30 years | “Metal against damp dirt” eventually rusts; the common failed well homeowners replace |
| Plastic / composite | Varies | Lighter, but less structural for deep wells and ladders |
Source: Abarent.
The rusted, collapsing corrugated-metal well is the one Calgary homeowners replace most often. A precast concrete well doesn’t rust, holds soil pressure through its mass, and integrates a built-in egress ladder or step for wells over 1.2 m — which is exactly where the durability and code requirements meet.
How do I stop my window well from flooding?
Drainage is where most egress wells fail and basements get wet. The detail: place 4–6″ of clear stone/gravel at the base of the well, with the top of the gravel sitting below the window sill, and tie that gravel to the home’s perimeter drainage (weeping tile) so water moving through the well goes down and away rather than pooling against the window (Shield Foundation Repair). A well that traps water against the sill will leak no matter how good the window is. “Make your suite legal — and dry” is one job, not two: the code gets you the permit; the drainage keeps the basement dry.
FAQ
What are Calgary’s egress window requirements for a legal bedroom or suite in 2026? The opening must give at least 0.35 m² (3.77 sq ft) of unobstructed area, with no dimension under 380 mm (15″), a sill no higher than 1.5 m above the finished floor, and it must open from inside without tools. The window well needs at least 760 mm of clear projection. These come from NBC(AE) 2023 Part 9 and the City of Calgary Egress Window Guidelines.
Do I need a permit to cut my foundation for an egress window? Yes. A City of Calgary building permit is required for any new or enlarged egress window because cutting the foundation wall is structural — the Building Code limits the size and percentage of openings allowed in a foundation wall. Fees start around $333.84, and unpermitted work voids insurance and fails inspection.
How deep can a window well be before it needs a ladder? 1.2 m (4 ft). Any window well deeper than that must have a permanently built-in ladder or steps so a person can climb out.
Does my basement suite need to be registered in Calgary? Yes, if it’s a secondary suite (bathroom + cooking facilities). It needs a building permit and must appear on the City of Calgary Secondary Suite Registry to be a legal rental. The egress windows are part of what the inspection verifies.
Concrete vs metal vs plastic window well — which is best for Calgary? Concrete. It lasts 30–50+ years with no rust, rot, or UV breakdown, retains soil through its mass, and carries a built-in egress ladder cleanly. Galvanized steel lasts 20–30 years but eventually rusts where metal meets damp soil — it’s the well Calgary homeowners most often replace.
How do I stop my window well from flooding? Put 4–6″ of clear gravel at the base of the well with the top of the gravel below the window sill, and tie it into the home’s weeping tile so water drains down and away instead of pooling against the window.
What does an egress window and well project cost in Calgary? The permit alone starts around $333.84; the full project adds the window, the foundation cut, the well, and installation, which vary by access and depth. See the precast pricing guide for ranges, and validate against a current Calgary quote.
What code does Calgary use — IRC or NBC? NBC(AE) — the National Building Code, Alberta Edition (2023), Part 9, plus the City of Calgary Egress Window Guidelines. Not the US IRC. American sites cite IRC Section R310 with different imperial numbers (5.7 sq ft, etc.) — those figures do not apply in Calgary and are a sign a source is using US references.
